Technical Specifications |
|
|
Application fields: |
Organ grinding, homogenization, cell disruption, tissue pulverization, material dispersion, preparation, sample mixing, and oscillation |
|
Processing capacity: |
Maximum processing capacity of 24 samples in 15 seconds, with integrated compressor cooling |
|
Compatible sample tubes: |
24*(0.2-0.5ML) /24*2ML /6*(7-15)ML /2*25ML /2*50ML, various specifications of grinding tubes can be custom-made |
|
Display: |
Touch screen display for convenient and intuitive operation |
|
Data storage: |
Can store ten sets of experimental data, with animal heart, spleen, lung, kidney, bone, skin, and hair patterns set according to different experimental samples |
|
Cycle mode: |
According to the set experimental parameters, it can cycle continuously between several pre-set parameters, further reducing interference from human factors |
|
Shock absorption principle: |
The innovative shock absorption principle of the German Schleifen-1 working mode and the three-dimensional motion of the up-down and left-right shaking- the innovative movement of the grinding beads, ensuring maximum sample processing and instant crushing effect |
|
Maximum feeding size: |
No requirement, adjustable according to the adapter |
|
Cooling function: |
Yes, adjustable from -30°C to 37°C |
|
Temperature control accuracy: |
+ 0.5°C |
|
Open lid operation protection: |
Electromagnetic lock |
|
Final discharge particle size: |
~5μm |
|
Number of grinding platforms: |
(acceptance of grinding jars) > 2 |
|
Fastening device: |
with automatic center positioning |
|
Homogenization speed: |
0~70 Hz/sec, working time: 0 sec~99 min, user-settable |
|
Diameter of grinding balls: |
0.1~30mm |
|
Material of grinding balls: |
alloy steel, chrome steel, zirconium oxide, tungsten carbide, quartz sand |
|
Acceleration: |
reaches maximum speed within 2 seconds |
|
Deceleration: |
reaches minimum speed within 2 seconds |
|
Noise level: |
<55db |
|
Grinding mode: |
wet grinding, dry grinding, and low-temperature grinding are all possible |
|
Temperature control can be additionally equipped with: |
the ability to be upgraded to ultra-low temperature liquid nitrogen cooling or air cooling |
|
Material of adapter: |
polytetrafluoroethylene, alloy steel |
|
Safety instructions: |
with automatic center positioning and safety lock during operation for full protection |
|
Material of grinding kit: |
hard alloy, polytetrafluoroethylene (Teflon), zirconium oxide |
|
Dimensions: |
630*300*480mm |
|
Weight: |
58 kg |
